Designed for critical safety in explosive atmospheres, Type C conductive FIBC bags are the ultimate choice when handling combustible dusts or working near flammable vapors. These groundable bulk bags feature a grid of interconnected conductive threads that must be earthed during filling and discharging to safely dissipate static electricity. Perfect for chemical and pharmaceutical industries, this explosion-proof flexible container eliminates the risk of incendiary sparks, providing a secure static control packaging for hazardous zones.
Order(MOQ) :
100Product Origin :
fujian,fuzhouColor :
As you demandLead Time :
30 days
Product categoriesThis Type-C conductive FIBC is manufactured using thickened PP woven fabric as the base material. During the weaving process, carbon fibers or conductive polyester filaments are uniformly integrated into the fabric structure at intervals of approximately 5–10 cm, forming a continuous and uninterrupted conductive network throughout the entire bag body.
When the bag’s dedicated grounding terminal is properly connected to an earthing device, static electricity generated during filling, discharge, or handling is rapidly conducted and safely dissipated, significantly reducing the risk of electrostatic accumulation at the source.
⚠️ Type-C FIBCs must always be grounded during use to ensure effective electrostatic protection.
Technical Overview
| Item | Specification |
|---|---|
| Product Type | Type-C Conductive FIBC |
| Base Material | Thickened PP woven fabric |
| Conductive Element | Carbon fiber / conductive polyester filaments |
| Conductive Spacing | Approx. 5–10 cm |
| Surface Resistance | 10⁴–10⁸ Ω |
| Grounding | Dedicated grounding terminal (mandatory) |
| Reuse Cycles | 5–8 cycles (typical) |
| Printing | “TYPE C Conductive FIBC”, ISO 7000-2415 |
| Customization | Size, color, liner, printing |
Quality Inspection Checklist
| Inspection Item | Purpose |
|---|---|
| Conductivity Continuity Test | Ensures an uninterrupted conductive path exists between the grounding terminal and the conductive fiber network |
| Surface Resistance Test | Verifies 10⁴–10⁸ Ω range |
| ESD Performance Test | Confirms controlled static dissipation |
| Structural Inspection | Sewing, fabric & leakage prevention |
Product Identification & Safety Marking
| Marking | Description |
|---|---|
| Product Type | “TYPE C Conductive FIBC” |
| Safety Symbol | ISO 7000-2415 grounding symbol |
| Warning | “GROUNDING REQUIRED” |
Versatile solutions for various sectors
New energy battery material manufacturing: Suitable for sensitive materials such as lithium iron phosphate (LFP) powder, anode materials, and Lithium Cobalt Oxide (LCO) powder. It rapidly dissipates static electricity to significantly reduce the risk of dust ignition. Simultaneously, it aligns with the automated feeding requirements of dust-free workshops, supporting both the purity of battery materials and enhanced production safety.
Chemical industry: designed for materials such as titanium dioxide, masterbatch, and filler powders. It enables dust-free discharge to prevent contamination, while providing dual functionality of anti-static and explosion-proof protection.
Powder metallurgy industry: Custom-designed for metal powders such as aluminum, zinc, and copper, which are prone to oxidation and volatility. It provides dual protection against static electricity and potential combustion, suppressing spark discharge to minimize ignition hazards. This facilitates cleaner warehousing and efficient material turnover, aiming to minimize material loss and promote safer operations.
Tailor the bag to your exact specifications
Fully Integrated Manufacturer Controlling Every Step From Granule To Bag
1. Consistent Quality
We meticulously manufacture our products using virgin PP material, guaranteeing superior quality right from the raw material stage.
2. Weaving & Testing:
Our advanced looms produce high-tensile fabric, strictly tested for UV resistance and breaking strength.
3. Finished Product:
Skilled sewing and rigorous inspection ensure every bag meets ISO safety standards.
